go back- Publish date: 02/25/2016
- Product release date: 01/16/2016
- Product Version: R3.82
- Product Webpage
Exaopc OPCインタフェースパッケージ
Exaopc（エグザオーピーシー）はYOKOGAWAの統合生産制御システムCENTUM向けに提供されるOPCサーバソフトウェアです。YOKOGAWA独自の制御バスであるVnet/IPに接続し、OPCおよびOPC UA標準インタフェースを介して CENTUMから直接データを取得し、外部システムへ提供します。これにより、製造現場のデータ活用を強力に支援します。
Product details
Markets:
|
Category: Gateway |
Supported Profiles and Facets
Application Profiles:
UACore 1.04
- Standard 2017 UA Server Profile
Additional Facets:
UACore 1.04
- Client Redundancy Server Facet
- Data Access Server Facet
- Method Server Facet
- Standard Event Subscription Server Facet
Security Policies:
UACore 1.04
- SecurityPolicy - Aes256-Sha256-RsaPss
- SecurityPolicy [A] - Aes128-Sha256-RsaOaep
- SecurityPolicy [B] – Basic256Sha256
- SecurityPolicy – Basic128Rsa15
- SecurityPolicy – Basic256
- SecurityPolicy – None
User Tokens:
UACore 1.04
- User Token – Anonymous Server Facet
- User Token – User Name Password Server Facet
- User Token – X509 Certificate Server Facet
Product certification history
| Certified Profiles | Standard 2017 UA Server Profile |
| Certificate Number | 2603CE0126 |
| Certification Date | 03/06/2026 |
| Expiration Date | 03/31/2029 |
| CTT Version | 1.04.11-01.00.510 |
| Additional Facets | Client Redundancy Facet, Data Access Server Facet, Standard Event Subscription Server Facet, Method Server Facet |
| Security Policies | SecurityPolicy – None, SecurityPolicy – Basic128Rsa15, SecurityPolicy – Basic256, SecurityPolicy [B] – Basic256Sha256, SecurityPolicy [A] - Aes128-Sha256-RsaOaep, SecurityPolicy - Aes256-Sha256-RsaPss |
| User Identity Tokens | User Token – Anonymous Server Facet, User Token – User Name Password Server Facet, User Token – X509 Certificate Server Facet |
| Product Name | Exaopc |
| Certified Product Version | R3.82.01 |
| Product MD5 Hash | 68a136f8b91ba92f65e6167a62d78073 |
