OpreX Open Automation SI Kit
The components working in a DCN include an OPC UA server supporting the O-PAS information model, GDS client function and Alias Name Service.
Product details
| Category: SDK |
Supported Profiles and Facets
Application Profiles:
UACore 1.04
- Standard 2017 UA Server Profile
Additional Facets:
UACore 1.04
- Core 2017 Server Facet
- Embedded DataChange Subscription Server Facet
- Enhanced DataChange Subscription 2017 Server Facet
- Standard DataChange Subscription 2017 Server Facet
- Standard Event Subscription Server Facet
- UA-TCP UA-SC UA-Binary
Security Policies:
UACore 1.04
- SecurityPolicy - Aes256-Sha256-RsaPss
- SecurityPolicy [A] - Aes128-Sha256-RsaOaep
- SecurityPolicy [B] – Basic256Sha256
- SecurityPolicy – Basic128Rsa15
- SecurityPolicy – Basic256
- SecurityPolicy – None
User Tokens:
UACore 1.04
- User Token – Anonymous Facet
- User Token – User Name Password Server Facet
- User Token – X509 Certificate Server Facet
Supported Conformance Units
UACore 1.04
- Attribute Write Values
- Base Info Custom Type System
- Base Info Diagnostics
- Base Info Engineering Units
- Base Info Server Capabilities
- Base Info ValueAsText
- Security Administration
- Session Change User
Product certification history
| Certified Profiles | Standard 2017 UA Server Profile |
| Certificate Number | 2603CE0129 |
| Certification Date | 03/30/2026 |
| Expiration Date | 03/31/2029 |
| CTT Version | 1.04.11-01.00.510 |
| Additional Facets | AliasName Server Facet, Documentation Server Facet, Global Certificate Management Server Facet, User Role Management Server Facet, Enhanced DataChange Subscription 2017 Server Facet, Data Access Server Facet, Auditing Server Facet, Address Space Notifier Server Facet, Security Time Synchronization, Security User Access Control Base, Best Practice – Audit Events, Best Practice – Random Numbers, Best Practice – Timeouts, Best Practice – Administrative Access Best Practice – Strict Message Handling, Embedded DataChange Subscription Server Facet, Standard DataChange Subscription 2017 Server Facet, Standard Event Subscription Server Facet, UA-TCP UA-SC UA-Binary |
| Security Policies | SecurityPolicy – None, SecurityPolicy – Basic128Rsa15, SecurityPolicy – Basic256, SecurityPolicy [B] – Basic256Sha256, SecurityPolicy [A] - Aes128-Sha256-RsaOaep, SecurityPolicy - Aes256-Sha256-RsaPss |
| User Identity Tokens | User Token – Anonymous Facet, User Token – Anonymous Server Facet, User Token – User Name Password Server Facet, User Token – X509 Certificate Server Facet |
| Companion Facets | OCF-001 |
| Product Name | OPAServer |
| Certified Product Version | 1.2.10.0 |
| Product MD5 Hash | 47749f4077eee6b2f3286d16532838b7 |
