  • Publish date: 08/19/2014
  • Product release date: 09/18/2023
  • Product Version: 12
  • Product Webpage
zenon OPC UA Process Gateway
COPA-DATA www.copadata.com

zenon OPC UA Process Gateway

The fully integrated OPC UA Process Gateway in the zenon Software Platform, enables secure exchange of real-time data from field devices and calculated or aggregated data from the control system with third-parties (such as MES or ERP software). Open interfaces and over 300 native drivers and communication protocols support the horizontal and vertical integration.

Product details

Markets:
  • Automotive
  • Biotechnology
  • Building Automation
  • Chemicals
  • Energy and Power
  • Food & Beverages
  • Machine Manufacturing
  • Medical Devices
  • Oil & Gas
  • Packaging
  • Pharmaceuticals
  • Pulp & Paper
  • Water & Waste Management
 Category: Gateway

Supported Profiles and Facets

Application Profiles:

  • UACore 1.04
    • Embedded 2017 UA Server Profile

Additional Facets:

  • UACore 1.04
    • UA-TCP UA-SC UA-Binary

Security Policies:

  • UACore 1.04
    • SecurityPolicy - Aes256-Sha256-RsaPss
    • SecurityPolicy [A] - Aes128-Sha256-RsaOaep
    • SecurityPolicy [B] – Basic256Sha256
    • SecurityPolicy – Basic128Rsa15
    • SecurityPolicy – Basic256
    • SecurityPolicy – None

User Tokens:

  • UACore 1.04
    • User Token – Anonymous Server Facet
    • User Token – User Name Password Server Facet
    • User Token – X509 Certificate Server Facet

Capacities
Max. SecureChannels: 50
Max. Sessions: 50
Max. Subscriptions: 500
Max. Monitored Items: 32767500
Max. Monitored Items Per Subscription: 65535
Monitored Item Queue: 100
Publish Request Queue: 10
Fastest Sampling: 250
Fastest Publishing: 250
Number Of Continuation Points: 1

Product certification history

Certified Profiles Embedded 2017 UA Server Profile
Certificate Number 2310CE010A
Certification Date 10/16/2023
Expiration Date 10/31/2026
CTT Version 1.04.11-01.00.502
Security Policies SecurityPolicy – Basic128Rsa15,
SecurityPolicy – Basic256,
SecurityPolicy [B] – Basic256Sha256,
SecurityPolicy [A] - Aes128-Sha256-RsaOaep,
SecurityPolicy - Aes256-Sha256-RsaPss
User Identity Tokens User Token – Anonymous Server Facet,
User Token – User Name Password Server Facet,
User Token – X509 Certificate
Product Name zenon OPC UA Process Gateway
Certified Product Version 12
Product MD5 Hash 4d2b53b52e33bd19dc7e33c11ec10a62
Embedded 2017 UA Server Profile
Certified Profiles Standard UA Server
Certificate Number 1207CS0026
Certification Date 07/24/2012
Expiration Date 07/31/2015
CTT Version 1.1.0.2819
Product Name Zenon OPC UA Server
Certified Product Version 6.51 SPO Build10
Standard UA Server
