go back- Publish date: 03/03/2016
- Product release date: 05/03/2021
- Product Version: 3.18
- Product Webpage
SCADA system SIMATIC WinCC Open Architecture
SIMATIC WinCC Open Architecture is part of the SIMATIC HMI family and designed for applications of large scale and high complexity as well as projects with special requirements on system perequisites and customized functionality.
SIMATIC WinCC Open Architecture supports:
- OPC UA DA (Data Access) (Client & Server)
- OPC UA AC (Alarms & Conditions) (Client & Server)
- OPC UA HA (Historical Access) (Client & Server)
Highlights SIMATIC WinCC Open Architecture:
- Object orientation enables efficient engineering and flexible system expansion
- Distributed systems up to 2,048 servers
- Scalable – from small single-user systems to distributed, redundant high-end systems with more than 10 million tags
- Platform-independent and available for Windows, Linux, iOS and Android
- Hot standby redundancy and Disaster Recovery System ensure the highest levels of system reliability and availability
- Platform for customer-specific solutions
Product details
| Category: SCADA |
Supported Profiles and Facets
Application Profiles:
UACore 1.04
- Standard 2017 UA Server Profile
Additional Facets:
UACore 1.04
- A & C Acknowledgeable Alarm Server Facet
- A & C Address Space Instance Server Facet
- A & C Alarm Server Facet
- Address Space Notifier Server Facet
- Historical Raw Data Server Facet
- Redundancy Visible Server Facet
- Standard Event Subscription Server Facet
Security Policies:
UACore 1.04
- SecurityPolicy - Aes256-Sha256-RsaPss
- SecurityPolicy [A] - Aes128-Sha256-RsaOaep
- SecurityPolicy [B] – Basic256Sha256
- SecurityPolicy – Basic128Rsa15
- SecurityPolicy – Basic256
- SecurityPolicy – None
User Tokens:
UACore 1.04
- User Token – Anonymous Facet
- User Token – User Name Password Server Facet
- User Token – X509 Certificate Server Facet
Supported Profiles and Facets
Application Profiles:
UACore 1.04
- Minimum UA Client Profile
Additional Facets:
UACore 1.04
- A & C Address Space Instance Client Facet
- A & C Alarm Client Facet
- A & C Exclusive Alarming Client Facet
- A & C Non-Exclusive Alarming Client Facet
- AddressSpace Lookup Client Facet
- Attribute Read Client Facet
- Attribute Write Client Facet
- Base Client Behaviour Facet
- Core 2017 Client Facet
- DataChange Subscriber Client Facet
- Discovery Client Facet
- Event Subscriber Client Facet
- Historical Access Client Facet
- Method Client Facet
- Redundancy Switch Client Facet
- Redundant Client Facet
Security Policies:
UACore 1.04
- SecurityPolicy - Aes256-Sha256-RsaPss
- SecurityPolicy [A] - Aes128-Sha256-RsaOaep
- SecurityPolicy [B] – Basic256Sha256
- SecurityPolicy – Basic128Rsa15
- SecurityPolicy – Basic256
- SecurityPolicy – None
User Tokens:
UACore 1.04
- User Token – Anonymous Facet
- User Token – User Name Password Client Facet
- User Token – X509 Certificate Client Facet
Information Models
- PackML 1.01
- Data Access 2.05a
- Alarms and Events
- Historical Data Access
- Data Access 2.05a
- Alarms and Events
- Historical Data Access
Product certification history
| Certified Profiles | Standard 2017 UA Server Profile, Minimum UA Client Profile, Data Access 2.05a |
| Certificate Number | 2206CE00F0 |
| Certification Date | 06/17/2022 |
| Expiration Date | 06/30/2025 |
| CTT Version | 1.04.9.398, 2.00.15.1152 |
| Additional Facets | Standard Event Subscription Server Facet, Address Space Notifier Server Facet, A & C Alarm Server Facet, A & C Address Space Instance Server Facet, A & C Acknowledgeable Alarm Server Facet, Historical Raw Data Server Facet, AddressSpace Lookup Client Facet, Method Client Facet, Attribute Read Client Facet, Attribute Write Client Facet, DataChange Subscriber Client Facet, Base Client Behaviour Facet, Core 2017 Client Facet, Discovery Client Facet |
| Security Policies | SecurityPolicy – None, SecurityPolicy – Basic128Rsa15, SecurityPolicy – Basic256, SecurityPolicy [B] – Basic256Sha256, SecurityPolicy [A] - Aes128-Sha256-RsaOaep, SecurityPolicy - Aes256-Sha256-RsaPss |
| User Identity Tokens | User Token – Anonymous Facet, User Token – User Name Password Server Facet, User Token – X509 Certificate Server Facet, User Token – User Name Password Client Facet, User Token – X509 Certificate Client Facet |
| Product Name | SIMATIC WinCC Open Architecture |
| Certified Product Version | 3.18 |
| Product MD5 Hash | df3cd91c92111cb6b44fb023c10cfb63 |
| Certified Profiles | Standard UA Server, Core Client Facet, Data Access 2.05a |
| Certificate Number | 1807CE00AC |
| Certification Date | 07/15/2018 |
| Expiration Date | 07/31/2021 |
| CTT Version | OPC UA: 1.03.340.380 OPC Classic: DA 3.0 1.0.18 |
| Additional Facets | Attribute Read Client, Attribute Write Client |
| Product Name | SCADA system SIMATIC WinCC Open Architecture |
| Certified Product Version | 3.16.54028428 |
